Light Source:

• 7x Osram 40W RGBW (4-IN-1) LEDs

Features:

• IP65 outdoor rated – protects fixture from dust, sand, moisture and liquid (Temporary outdoor use only)

• Motorized Zoom: 6 ~ 40-degrees

• Firmware Upgrade: Update via IP65 USB port (with rubber protective covers over connections)

• Antenna Range: 98.42ft (30m)

Construction:

• Color display with touch buttons

• Data In/Out: 5-pin DMX IP65 (with rubber protective covers over connections)

• Power In/Out: locking IP65 (with rubber protective covers over connections)

• All metal case design

Control:

• WiFLY Wireless DMX built-in (Up to 2,500 ft / 700M line of sight)

• 3 DMX channel modes: 15, 17 & 41 channels

• Control modes: DMX-512, RDM (Remote Device Management)

• Pixel Control

• 0-100% dimming plus 16-bit fine dimming

• 6 dimmer curve modes

• Shutter control

• Strobe & pulse effects

• Gamma correction: 1.0, 2.0, 2.2, 2.4, 2.6 and 2.8

• With Wired Digital Communication Network

Pan/Tilt:

• Pan/Tilt: 540-degrees / 255-degrees

• 16-bit Fine Pan

• 16-bit Fine Tilt

 Electrical:

• Multi-voltage operation: 100-240V, 50/60Hz

• Min/Max Ambient Temperature: -10ºC ~ 40ºC

Dimensions & Weight:

• Dimensions (LxWxH): 8.5”x12”x18” / 215x302x457mm

• Weight: 35 lbs. / 16kg.

Optional Road Cases:

• DRC MH: 2 Hydro Wash X7 fit in the DRC MH Road Case

• QRC MH: 4 Hydro Wash X7 fit in the QRC MH Road Case

Rating / Approvals:

• cETLus Approved (Control #4000358)
