Light Source:

• OSRAM Sirius HRI 310W PRO Discharge Lamp (6,000 hr.)

• Color temperature: 7850K (+/- 500K)

• CRI: 86 (+/- 5)

Features:

• CMY Color Mixing

• On-Board Wireless DMX

• Motorized Focus + 16-bit fine focus

• 2-degree beam angle

• Frost Filter to create wash effect

• High quality glass lens

• 2 Rotating prisms:

• 0-100% smooth dimming

• Pan/Tilt locks

• Various strobe speeds

• OTA, wireless, firmware updates

• Fan cooled

Color Wheel:

• 14 dichroic colors + white (Includes CTO (3200K), CTB (9000k) & UV)

• Indexable color wheel for split colors

• Separate Multi-Color Effect

GOBO Wheel:

• 17 static GOBOs + open (4 GOBOs are beam reducers)

• GOBO Shake Effect

Prism Wheels:

• 2 Rotating prisms

• 16 facet circular and 6 facet linear prisms

• Prisms Overlay

Control:

• Protocols: DMX512 & RDM

• Control Mode: DMX512 & Manual (On-board Controls)

• 2 DMX Channel Modes: 20/24 Channels

• Aria X2 Wireless Management / DMX System

• Color LCD display with 4-button function menu

• 0-100% smooth dimming

• Various strobe speeds

• With Wired Digital Communication Network

Pan/Tilt:

• Pan: 540 degrees (plus 16-bit fine pan)

• Tilt: 270 degrees (plus 16-bit fine tilt)

• 3 Phase, High Speed, Pan/Tilt motors

Connections:

• DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)

• Power Connections: Outdoor locking In/Out connections to daisy chain power

Electrical:

• Multi-voltage operation: 100-240V, 50/60Hz

• Max power consumption: 410W (@120V), 390W (@230V)

• Fuze Protected: 6.5A

Dimensions & Weight:

• Dimension: 9.8” (L) x 14.3” (W) x 17.9” (H) / 248 x 364 x 454.8mm

• Weight: 38.5 lbs. / 17.5 kg.

Approvals / Ratings

• CE

• cETLus (Control # 5028947)

• FCC

What’s Included:

• 2x Omega Brackets (107 Type)

• 2M, outdoor locking 14AWG power cord

Accessories (Sold Separately):

• DRC MHX - Dual Moving Head Road Case

• Quick Rig Clamp

• Quick Rig Clamp BLK

• Pro-Clamp

• Accu-Cable Tour Link 5P15 - 15ft. 5-pin male/female professional grade DMX Cable

• SIP152 - 16ft., IP65-Rated male to female locking power cord

Specifications are subject to change without notice.

UPC: 810087372477
