ADJ Vizi Beam RX2 - 100W Moving Head Beam
ADJ Vizi Beam RX2 - 100W Moving Head Beam
The ADJ Lighting Vizi Beam RX2 is a compact, high-performance moving head beam fixture that features a 100W Osram Sirius HRI discharge lamp, a razor-sharp 2-degree beam, two prism effects, and a host of high-performance features for the modern lighting professional.
Light Source:
OSRAM Sirius HRI 100W Discharge Lamp (6,000 hr.)
Color temperature: 9000K (+/- 300K)
Features:
On-Board Wireless DMX
Motorized Focus + 16-bit fine focus
2-degree beam angle
Frost Filter to create wash effect
High quality glass lens
2 Rotating prisms:
0-100% smooth dimming
Various strobe speeds
OTA, wireless, firmware updates
Fan cooled
Color Wheel:
14 dichroic colors + white (Includes CTO (3200K), CTB (4500K & 9000K) & UV filters)
Indexable color wheel for split colors
GOBO Wheel:
15 static GOBOs + open (3 GOBOs are beam reducers)
GOBO Shake Effect
Prism Wheels:
2 Rotating prisms
16- facet circular and 4-facet linear prisms
Control:
Protocols: DMX512 & RDM
Control Mode: DMX512 & Manual (On-board Controls)
2 DMX Channel Modes: 12/16 Channels
Aria X2 Wireless Management / DMX System
Color LCD display with 4-button function menu
0-100% smooth dimming
Various strobe speeds
With Wired Digital Communication Network
Pan/Tilt:
Pan: 540 degrees (plus 16-bit fine pan)
Tilt: 270 degrees (plus 16-bit fine tilt)
3 Phase, High Speed, Pan/Tilt motors
Connections:
DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)
Power Connections: Outdoor locking In/Out connections to daisy chain power
Electrical:
Multi-voltage operation: 100-240V, 50/60Hz
Max power consumption: 168W (@120V), 157W (@230V)
Fuze Protected: 3.15A
Dimensions & Weight:
Dimension: 9” (L) x 12” (W) x 16.3” (H) (230 x 304 x 416mm)
Weight: 16.5 lbs. / 7.5 kg.
Approvals / Ratings
CE
cETLus (Control # 5028947)
FCC
What’s Included:
2x Omega Brackets (107 Type)
2M, outdoor locking 14AWG power cord
Road Cases:
Specifications are subject to change without notice.
UPC: 810087372484
